Gang Type Tool Holder Turret TCK36 CNC Lathe Milling Machine for Precise Production

Ask Lasest Price
Brand Name :	Lu Young
Model Number :	TCK36
Price :	$25,000.00/sets 1-1 sets

Add to Cart

Product Details
Company Profile

Gang Type Tool Holder Turret TCK36 CNC Lathe Milling Machine for Precise Production

shangdong manufacturer cnc lathe milling machine tck36 lathe machine cnc automatic slant bed lathe with milling

Product Description

Gang Type Tool Holder Turret TCK36 CNC Lathe Milling Machine for Precise Production

shangdong manufacturer cnc lathe milling machine tck36 lathe machine cnc automatic slant bed lathe with milling is mainly used for processing various shaft, disk parts, turning can be all kinds of screw thread, arc, cone and plane of internal and external surface can satisfy the ferrous and non-ferrous metals the speed requirement of high-speed chip. Suitable for cars, motorcycles, electronics, aerospace and other industries to high efficiency, large quantity and high precision of parts processing Machining precision can reach level 7.

Products feature

shangdong manufacturer cnc lathe milling machine tck36 lathe machine cnc automatic slant bed lathe with milling

*High precision Taiwan linear guide
*Large and convenient chip removal,right chip removal and rear chip removal can be selected.
*The spindle unit is divided into two types:heavy cutting and high speed
*The heavy-cut spindle unit is suitable for processing bearings and gears
*High-speed spindle unit is suitable for high-speed and high-precision machining
*Screw pre-tensioned construction
*Row Tool Holder.Optional turret

Specification

Model	TCK36
Max swing over bed dia.	φ350
Max swing over crosslide dia.	φ110
Max cutting diameter(mm)	φ300
Max cutting length(mm)	300
X axis(mm)	280
Z axis(mm)	300
X axis fast moving	20
Z axis fast moving	20
Spindle speed	1600/3500rpm
Positioning accuracy(mm)	0.016
Repeatability(mm)	0.008
Gradient	45°
Max turning speed(mm/rpm)	1-6000
Spindle bore(mm)	φ65
Spindle nose	A2-6
Spindle taper	1:20
Main motor power(kW)	7.5
Manual Chuck	8”
Turret type	gang type holder
Tailstock sleeve stroke(mm)	----
Cross Weight	1800kg
Dimensions(mm)	2070 X1630X1860
Standard configuration:
1.6 stations electric tool post
2.Taiwan Hiwin Linear guideways
3.Manual tail stock
4.8”manual chuck
5.Light system, auto lubrication system, coolant system
6.Machine instruction manual

Packing & Delivery

1.Port: Qingdao port or Shanghai port 2.Payment method: T/T, L/C, D/P, D/D etc. 3.Payment: 30% T/T as deposit, 70% balance shall be paid before shipment. 4.Delivery time: 30 days after receive the 30%T/T deposit.5.Non-fumigation packaging, we use seaworthy plywood. 6. Steel base plate, it is stronger 3-5 times than normal plywood base plate. 7.Water-proof and damp proof, water resistant film wraped all the machine.

Company Profile

Shandong Lu Young Machinery Co., Ltd., is a modern and high- tech company which is a professional manufacturer of CNC LATHE, CNC MILLING, CNC MACHINE CENTER . With 5,000sqm workshops and offices, we have more than 20 years experiences in cnc machine research and production.Our machines have been exported more than 40 countries.we welcome all customers and friends to come to our company! Regarding the technical force, we have the most professional research and development staff, who can meet all different requirements on technology and production. For the sales, there are internal trade department and international trade department. They are all professional salespersons who can help you solve problems on purchase and technology related to the CNC tools and test machines. Our products are sold both at home and abroad, and they are very popular around the world. All of products have pass CE certification.Welcome to contact with us to make business!!

Certifications

With strong economic strength, advanced technical equipment and perfect testing means, our company has forged the excellent quality of our products. Our company is based on quality, market-oriented, customer-centered and service-oriented. Our company has won the civilized and honest private enterprise of Shandong Province, advanced unit of independent innovation in Shandong Province machinery industry, with the qualification of utility model patent certificate.

Exhibition

Our company has participated in a number of exhibitions to showcase our quality products. With our high quality products, advanced technology and equipment, and enthusiastic service, we have attracted a large number of customers at the exhibitions and have received unanimous praise.

FAQ

1. Who are we?
We are based in Shandong, China, start from 2015,sell to Eastern Europe(33.00%),Southeast Asia(17.00%),South America(13.00%),Western Europe(8.00%),Mid East(8.00%),South Asia(4.00%),North America(4.00%),Central America(4.00%),Northern Europe(4.00%),Africa(4.00%). There are total about 11-50 people in our office.

2.How long is the warranty period of the machine?
Warranty period is one year, if parts damage within one year, we will send free of charge. Free online training or factory
training to ensure that you can use our products properly. We can offer overseas paid installation, commissioning service.

3.What can you buy from us?
CNC Lathe Machine, CNC Milling Machines, Manual Lathe Machine, Metal Band Saw Machines, Manual Milling Machine

4. Why should you buy from us not from other suppliers?
20 Years Experiences Research and Development for CNC Machine Friendly Factory Price and High Quality Professional technology team to help you choose the most suitable configuration. 7X24 hours telephone and online service for free.

5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
